NSComm 25G SFP28 to SFP28 Active Optical Cable, OM3 Multimode, up to 30m
25G SFP28 to SFP28 Active Optical Cable (AOC), OM3, up to 30 m (98 ft), Custom up to 70 m (230 ft)
Overview
The NSComm 25G SFP28 to SFP28 Active Optical Cable (AOC) is a premium-quality, cost-efficient 25 Gigabit Ethernet interconnect solution designed for high-density data center environments.
It operates over OM3 multimode fiber, offering stocked lengths up to 30 m (98 ft), and custom lengths up to 70 m (230 ft) available upon request.
This cable features hot-swappable SFP28 connectors for seamless deployment and maintenance. Built with enhanced EMI shielding and low typical power consumption (≤1 W per end), it maintains signal integrity and energy efficiency.
Integrated Digital Optical Monitoring (DOM) via the I²C interface allows real-time diagnostics and performance monitoring.
The NSComm 25G AOC is fully compliant with SFP28 MSA standards - including SFF-8431, SFF-8432, and digital diagnostics (SFF-8472) and meets IEEE 802.3by specifications.
It is thoroughly tested for interoperability with Cisco, Huawei, Juniper, Arista, Dell, Netgear, Intel, HPE Aruba, Fortinet, and other mainstream network equipment.
Compatible Brands
NSComm 25G SFP28 AOC works seamlessly with devices from leading Ethernet switch and server vendors, including but not limited to Cisco, Huawei, Juniper, Arista, Dell, Netgear, Intel, HPE Aruba, Fortinet, and more.
Need compatibility confirmation for your specific model? [Contact Us Now] and our technical team will assist.
Key Specifications
| Specification | Details |
|---|---|
| Vendor Name | NSComm |
| Product Type | 25G SFP28 to SFP28 Active Optical Cable (AOC) |
| Data Rate | 25 Gbps (25.78125 Gbps per lane) |
| Fiber Type | OM3 Multimode Fiber |
| Max Cable Distance | 30 m (98 ft) stocked; up to 70 m (230 ft) custom |
| Connector Type | SFP28 to SFP28 |
| Monitoring Feature | Digital Optical Monitoring (DOM) via I²C (SFF-8472) |
| Power Consumption | ≤ 1 W per end |
| Temperature Range | 0 °C to 70 °C (Commercial) |
| Housing & EMI Protection | Enhanced all-metal shielding for superior EMI immunity |
| Standards Compliance | IEEE 802.3by, SFF-8431, SFF-8432, SFF-8472, RoHS-compliant |
| Applications | Server-switch links, in-rack and adjacent rack connectivity |
Length Options
Standard lengths (in stock):
-
1 m (3 ft), 3 m (10 ft), 5 m (16 ft), 7 m (23 ft), 10 m (33 ft), 15 m (49 ft), 20 m (66 ft), 30 m (98 ft)
Custom lengths available on request:
-
50 m (164 ft), 70 m (230 ft)
Why Choose NSComm 25G AOC?
-
Flexible length offerings: Ready stock up to 30 m (98 ft); additional lengths up to 70 m (230 ft) available via customization.
-
Efficient and low-power: Uses ≤ 1 W per end, minimizing energy overhead.
-
Simple deployment: Hot-swappable connectors enable fast, tool-less installation.
-
Robust diagnostics: Integrated DOM ensures continuous, real-time link monitoring.
-
Broad interoperability: Validated across major networking brands for hassle-free integration.
More Details
Quality Certifications
Warranty
100% Low Price Guarantee
Network-switch.com provides high-quality products at low wholesale prices
100% Quality Assurance
All items are ORIGINAL and GENUINE only.
Item conditions are "New Sealed". They are fully tested by Certified CCIE / HCIE / RCNP Engineers.
Free Technical Support
Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.
100% Money Back Guarantee
You can contact our customer service team to exchange or return any product that you bought from us.
Standard Warranty Policy
Original New Sealed Enterprise Hardware: 3 Years
Original New Sealed Consumer Devices: 1 Year
The Support Contacts
If your NSComm products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
