NSComm 200G QSFP56 to QSFP56 Active Optical Cable, OM3 Multimode, up to 30m
200G QSFP56 to QSFP56 Active Optical Cable (AOC), OM3, up to 30 m (98 ft), Custom up to 100 m (328 ft)
Overview
The NSComm 200G QSFP56 to QSFP56 Active Optical Cable (AOC) provides a high-speed, low-latency, and energy-efficient solution for 200 Gigabit Ethernet interconnects in data centers, enterprise networks, and HPC clusters.
Built on OM3 multimode fiber, it supports standard stocked lengths up to 30 m (98 ft) and customized lengths up to 100 m (328 ft) to meet diverse deployment needs.
This AOC uses QSFP56 connectors on both ends, enabling 200 Gbps transmission with PAM4 modulation (4×50 Gbps lanes). It features hot-pluggable design, low power consumption (≤ 4.5 W per end), and excellent EMI immunity.
Integrated Digital Optical Monitoring (DOM) allows real-time monitoring of optical power, temperature, and link health, compliant with QSFP56 MSA and IEEE Ethernet standards.
Need help confirming support for your model? [Contact Us Now] and our experts will assist.
Key Specifications
| Specification | Details |
|---|---|
| Vendor Name | NSComm |
| Product Type | 200G QSFP56 to QSFP56 Active Optical Cable (AOC) |
| Data Rate | 200 Gbps (4×50 Gbps PAM4 lanes) |
| Fiber Type | OM3 Multimode Fiber |
| Max Cable Distance | 30 m (98 ft) standard; up to 100 m (328 ft) custom |
| Connector Type | QSFP56 to QSFP56 |
| Monitoring Feature | Digital Optical Monitoring (DOM) |
| Power Consumption | ≤ 4.5 W per end |
| Temperature Range | 0 °C to 70 °C |
| Bend Radius | Minimum 30 mm |
| Standards Compliance | QSFP56 MSA, IEEE 802.3cd, RoHS |
| Applications | 200G server-to-switch, switch-to-switch, high-bandwidth aggregation |
Why Choose NSComm 200G AOC?
-
Ultra-high bandwidth: 200 Gbps via 4×50 Gbps PAM4 lanes.
-
Flexible length options: Stocked up to 30 m (98 ft); custom builds up to 100 m (328 ft).
-
Energy-efficient design: ≤ 4.5 W per end, optimized for dense data centers.
-
DOM support: Real-time monitoring for reliability and uptime assurance.
-
Vendor interoperability: Tested with all major switch and server manufacturers.
Length Options
Standard stocked lengths:
1 m (3 ft), 2 m (7 ft), 3 m (10 ft), 5 m (16 ft), 7 m (23 ft), 10 m (33 ft), 15 m (49 ft), 20 m (66 ft), 30 m (98 ft)
Custom lengths available:
50 m (164 ft), 75 m (246 ft), 100 m (328 ft)
